Part Number

Type

Freq. Range

VSWR

Insertion Loss

Isolation

Switching time

Control

Power supply

Average Power

Work type

Connector

GHz

mAx

dB mAx

dB Min

ns mAx

V/A

W

MSW1-005010R

SPDT

0.5~1

1.5

1.3

80

200

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW1-010020R

SPDT

1~2

1.5

0.8

80

50

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW1-020040R

SPDT

2~4

1.5

1.2

80

50

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW1-020180R

SPDT

2~18

2.2

2

55

50

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW1-040080R

SPDT

4~8

1.6

1.5

60

50

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW1-060180R

SPDT

6~18

2

2.5

60

30

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW1-080120R

SPDT

8~12

1.7

1.8

60

50

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW1-0A2005R

SPDT

0.02~0.5

1.5

1.2

80

200

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW1-0A2030R

SPDT

0.02~3

2

2.2

60

200

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW1-120180R

SPDT

12~18

2

2

60

50

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW2-001045R

SP2T

0.1~4.5

2

2

70

50

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW2-004025

SP2T

0.4~2.5

1.5

1

80

100

TTL

±5V/50mA

1

Reflective

SMA-F

MSW2-005010R

SP2T

0.5~1

1.5

1.4

80

50

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW2-00A001R

SP2T

0.03~01

1.2

0.7

40

50

TTL

-5V(-50mA), -40V(-50mA)

50

Reflective

SMA-F

MSW2-00A010R

SP2T

0.02~1

1.5

1

35

100

TTL

-5V(-10mA), -40V(-10mA)

100

Reflective

SMA-F

MSW2-00A130R

SP2T

0.01~13

2

2

40

100

TTL

±5V/60mA

0.2

Reflective

SMA-F

MSW2-010020R

SP2T

1~2

1.3

0.8

60

2

TTL

+5V（300mA）/ -40V（-20mA）

20

Reflective

SMA-F

MSW2-010020R

SP2T

1~2

1.5

1

80

50

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW2-020040R

SP2T

2~4

1.3

1.3

40

50

TTL

-5V(-100mA), -40V(-50mA

50

Reflective

SMA-F

MSW2-020040R

SP2T

2~4

1.5

1.6

80

50

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW2-020180R

SP2T

2~18

2

2.5

55

50

TTL

100mA @+5Vdc/50mA@-12Vdc

0.2

Reflective

SMA-F

MSW2-020180R

SP2T

2~18

2.2

2.2

60

50

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW2-020200R

SP2T

2～20

2

2.8

50

100

TTL

±5V/60mA

0.2

Reflective

SMA-F

MSW2-040080R

SP2T

4~8

1.5

1.8

60

50

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW2-042044R

SP2T

4.2~4.4

2

1.5

60

70

TTL

±5V

1

Reflective

SMA-F

MSW2-044051R

SP2T

4.4~5.1

1.5

0.8

35

70

TTL

+5V (120mA) ,-20V(-10mA)

50

Reflective

SMA-F

MSW2-060090R

SP2T

6~9

1.5

1

35

1

TTL

+5V/100mA, -12V/10mA

50

Reflective

SMA-F

MSW2-080120R

SP2T

8~12

1.7

2

60

50

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW2-080160R

SP2T

8~16

2

2.8

60

80

TTL

±5V

1

Reflective

SMA-F

MSW2-0A2005R

SP2T

0.02~0.5

1.5

1.3

80

100

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW2-0A2030R

SP2T

0.02~3

2

2.3

60

100

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW2-120180R

SP2T

12~18

2.2

2.2

60

50

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW2-5800MR

SP2T

5.8

1.5

0.8

40

1

TTL

28V/100mA

80

Reflective

SMA-F

MSW3-005010R

SP3T

0.5~1

1.5

1.5

80

200

TTL

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW3-020040R

SP3T

2~4

1.5

1.3

80

50

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW3-020180R

SP3T

2~18

2.2

2.6

60

50

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW3-020200R

SP3T

2~20

2

2.8

50

200

TTL

±5V/60mA

0.2

Reflective

SMA-F

MSW3-040180R

SP3T

4~8

1.6

1.7

60

50

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW3-080120R

SP3T

8~12

1.7

2

60

50

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW3-0A2005R

SP3T

0.02~0.5

1.5

1.4

80

200

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW3-0A2030R

SP3T

0.02~3

2

2.4

60

200

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW3-120180R

SP3T

12~18

2

2.6

60

50

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW4-003160R

SP4T

0.3~16

2

3.2

55

100

TTL

+5V(+80mA), -5V(-40mA)

10

Reflective

SMA-F

MSW4-005010R

SP4T

0.5~1

1.5

1.6

80

200

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW4-010020R

SP4T

1~2

1.5

1.2

80

50

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW4-020040R

SP4T

2~4

1.5

1.4

80

50

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW4-020180R

SP4T

2~18

2.2

2.7

60

50

±5V/30mA

0.2

Reflective

SMA-F

MSW4-040080R

SP4T

4~8

1.6

1.8

60

50

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW4-044051R

SP4T

4.4~5.1

1.5

1.6

60

70

TTL

+5V (240mA) ,-20V(-10mA)

50

Reflective

SMA-F

MSW4-080120R

SP4T

8~12

1.7

2.1

60

50

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW4-0A2005R

SP4T

0.02~0.5

1.52

1.5

80

200

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW4-0A2030R

SP4T

0.02~3

2

2.5

60

200

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW4-120180R

SP4T

12~18

2

2.7

60

50

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW5-005010R

SP5T

0.5~1

1.5

1.6

80

200

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW5-010020R

SP5T

1~2

1.5

1.3

80

50

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW5-020040R

SP5T

2~4

1.5

1.5

80

50

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW5-020180R

SP5T

2~18

2.2

2.8

60

50

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW5-040080R

SP5T

4~8

1.6

1.8

60

50

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW5-080120R

SP5T

8~12

1.7

2.1

60

50

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW5-0A2005R

SP5T

0.02~0.5

1.52

1.5

80

200

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW5-0A2030R

SP5T

0.02~3

2

2.6

60

200

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW5-120180R

SP5T

12~18

2

2.9

60

50

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW6-003120R

SP6T

0.3~12

2

3.4

60

100

TTL

+5V(+100mA), -5V(-40mA)

10

Reflective

SMA-F

MSW6-005010R

SP6T

0.5~1

1.5

1.7

80

200

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW6-010020R

SP6T

1~2

1.5

1.4

80

50

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW6-020040R

SP6T

2~4

1.5

1.9

80

50

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW6-020040R

SP6T

2~4

1.5

1.6

80

50

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW6-020130R

SP6T

2~13

2

2

50

200

TTL

±5V/120mA

0.2

Reflective

SMA-F

MSW6-020180R

SP6T

2~18

2.2

3

60

50

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW6-040080R

SP6T

4~8

1.6

2

60

50

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW6-040180R

SP6T

4~18

2.5

4

40

50

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW6-044051R

SP6T

4.4~5.1

1.3

1.5

60

/

TTL

+5V (200mA), -12V (-10mA)

30

Reflective

SMA-F

MSW6-080120R

SP6T

8~12

1.7

2.8

60

50

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW6-0A2005R

SP6T

0.02~0.5

1.5

1.6

80

200

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW6-0A2030R

SP6T

0.02~3

2

2.7

60

200

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW6-120150R

SP6T

12~15

1.5

2.5

30

/

TTL

+5V (200mA), -12V (-10mA)

50

Reflective

SMA-F

MSW6-120180R

SP6T

12~18

2

3

60

50

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW7-005010R

SP7T

0.5~1

1.5

1.8

80

200

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW7-010020R

SP7T

1~2

1.5

1.4

80

50

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW7-020040R

SP7T

2~4

1.5

1.6

80

50

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW7-020180R

SP7T

2~18

2.2

3.3

60

50

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW7-040080R

SP7T

4~8

1.6

2

60

50

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW7-080120R

SP7T

8~12

1.7

2.5

60

50

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW7-0A2005R

SP7T

0.02~0.5

1.5

1.7

80

200

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW7-0A2030R

SP7T

0.02~3

2

2.8

60

200

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW7-120180R

SP7T

12~18

2

3.3

60

50

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW8-003120R

SP8T

0.3~12

2

3.5

60

100

TTL

+5V(+120mA), -5V(-50mA)

10

Reflective

SMA-F

MSW8-004025

SP8T

0.4~2.5

1.5

2

80

200

TTL

±5V/200mA

20

Reflective

SMA-F

MSW8-005010R

SP8T

0.5~1

1.5

1.8

80

200

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW8-010020R

SP8T

1~2

1.5

1.4

80

50

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW8-020040R

SP8T

2~4

1.5

1.7

80

50

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW8-020180R

SP8T

2~18

2.2

4

60

100

TTL

±5V/100mA

/

Reflective

SMA-F

MSW8-020180R

SP8T

2~18

2.2

3.5

60

50

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW8-040080R

SP8T

4~8

1.6

2.2

60

50

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW8-0A2005R

SP8T

0.02~0.5

1.5

1.7

80

200

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW8-0A2030R

SP8T

0.02~3

2

3

60

200

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSW22-075080R

SP22T

7.5~9

2

3

55

50

TTL

±5V/30mA

0.2

Reflective

SMA-F

MSWD2-060180T

SP2T

6~18

2

3.5

60

50

TTL

±5V/30mA

0.2

Reflective

SMA-F
